Description
iPhone 16 Pro Max A3296
The iPhone 16 Pro Max A3296 is the global edition, designed for extensive availability across many regions around the world. It supports Dual SIM functionality, allowing users to operate both a physical nano-SIM and an eSIM, while also offering Dual eSIM capabilities for added flexibility. A notable feature for users in Korea is the mandatory camera shutter sound, which remains active due to local regulations when taking photos within the country. This model is well-suited for those who need versatile SIM compatibility and seamless connectivity.
Network
Technology :
GSM / CDMA / HSPA / EVDO / LTE / 5G
2G bands :
GSM 850 / 900 / 1800 / 1900
CDMA 800 / 1900
3G bands :
HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100
CDMA2000 1xEV-DO
4G bands :
1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 30, 32, 34, 38, 39, 40, 41, 42, 48, 53, 66 - A3296
1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 32, 34, 38, 39, 40, 41, 42, 48, 53, 66, 71 - A3084
1, 2, 3, 4, 5, 7, 8, 11, 12, 13, 14, 17, 18, 19, 20, 21, 25, 26, 28, 29, 30, 32, 34, 38, 39, 40, 41, 42, 48, 53, 66, 71 - A3295
1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 30, 32, 34, 38, 39, 40, 41, 42, 48, 66 - A3297
5G bands :
1, 2, 3, 5, 7, 8, 12, 20, 25, 26, 28, 30, 38, 40, 41, 48, 53, 66, 70, 75, 76, 77, 78, 79 SA/NSA/Sub6 - A3296
1, 2, 3, 5, 7, 8, 12, 14, 20, 25, 26, 28, 29, 30, 38, 40, 41, 48, 53, 66, 70, 71, 75, 76, 77, 78, 79, 258, 260, 261 SA/NSA/Sub6/mmWave - A3084
1, 2, 3, 5, 7, 8, 12, 14, 20, 25, 26, 28, 29, 30, 38, 40, 41, 48, 53, 66, 70, 71, 75, 76, 77, 78, 79 SA/NSA/Sub6 - A3295
1, 2, 3, 5, 7, 8, 12, 20, 25, 26, 28, 30, 38, 40, 41, 48, 66, 70, 75, 76, 77, 78, 79 SA/NSA/Sub6 - A3297
Speed :
HSPA, LTE, 5G, EV-DO Rev.A 3.1 Mbps
Launch
Announced :
2024, September 09
Status :
Available. Released 2024, September 20
Body
Dimensions :
163 x 77.6 x 8.3 mm (6.42 x 3.06 x 0.33 in)
Weight :
227 g (8.01 oz)
Build :
Glass front, glass back, titanium frame (grade 5)
SIM :
Nano-SIM + eSIM + eSIM (max 2 at a time; International)eSIM + eSIM (8 or more, max 2 at a time; USA)Nano-SIM + Nano-SIM (China)
IP68 dust tight and water resistant (immersible up to 6m for 30 min) Apple Pay (Visa, MasterCard, AMEX certified)
Display
Type :
LTPO Super Retina XDR OLED, 120Hz, HDR10, Dolby Vision, 1000 nits (typ), 2000 nits (HBM)
Size :
6.9 inches, 115.6 cm2 (~91.4% screen-to-body ratio)
Resolution :
1320 x 2868 pixels, 19.5:9 ratio (~460 ppi density)
Protection :
Ceramic Shield glass (2024 gen)
Always-On display
Platform
iOS 18, upgradable to iOS 18.4
Chipset :
Apple A18 Pro (3 nm)
CPU :
Hexa-core (2x4.05 GHz + 4x2.42 GHz)
GPU :
Apple GPU (6-core graphics)
Memory
Card slot :
No
Internal :
256GB 8GB RAM, 512GB 8GB RAM, 1TB 8GB RAM
NVMe
Main Camera
Triple :
48 MP, f/1.8, 24mm (wide), 1/1.28", 1.22µm, dual pixel PDAF, sensor-shift OIS 12 MP, f/2.8, 120mm (periscope telephoto), 1/3.06", 1.12µm, dual pixel PDAF, 3D sensor‑shift OIS, 5x optical zoom 48 MP, f/2.2, 13mm (ultrawide), 1/2.55", 0.7µm, PDAF TOF 3D LiDAR scanner (depth)
Features :
Dual-LED dual-tone flash, HDR (photo/panorama)
Video :
4K@24/25/30/60/100/120fps, 1080p@25/30/60/120/240fps, 10-bit HDR, Dolby Vision HDR (up to 60fps), ProRes, 3D (spatial) video/audio, stereo sound rec.
Selfie camera
Single :
12 MP, f/1.9, 23mm (wide), 1/3.6", 1.0µm, PDAF, OIS SL 3D, (depth/biometrics sensor)
Features :
HDR, Dolby Vision HDR, 3D (spatial) audio, stereo sound rec.
Video :
4K@24/25/30/60fps, 1080p@25/30/60/120fps, gyro-EIS
Sound
Loudspeaker :
Yes, with stereo speakers
3.5mm jack :
No
Comms
WLAN :
Wi-Fi 802.11 a/b/g/n/ac/6e/7, tri-band, hotspot
Bluetooth :
5.3, A2DP, LE
Positioning :
GPS (L1+L5), GLONASS, GALILEO, BDS, QZSS, NavIC
NFC :
Yes
Radio :
No
USB :
USB Type-C 3.2 Gen 2, DisplayPort
Features
Sensors :
Face ID, accelerometer, gyro, proximity, compass, barometer
Ultra Wideband (UWB) support (gen2 chip) Emergency SOS, Messages and Find My via satellite
Battery
Type :
Li-Ion 4685 mAh
Charging :
Wired, PD2.0, 50% in 30 min 25W wireless (MagSafe), 15W wireless (China only) 15W wireless (Qi2) 4.5W reverse wired
Misc
Colors :
Black Titanium, White Titanium, Natural Titanium, Desert Titanium
Models :
A3296, A3084, A3295, A3297, iPhone17,2
SAR :
1.01 W/kg (head) 1.15 W/kg (body)
SAR EU :
1.22 W/kg (head) 1.45 W/kg (body)
Price :
$ 925.93 / € 1,208.99 / £ 1,014.00
Tests
Performance :
AnTuTu: 1838828 (v10) GeekBench: 8606 (v6) 3DMark: 4731 (Wild Life Extreme)
Display :
1796 nits max brightness (measured)
Loudspeaker :
-24.4 LUFS (Very good)
Battery (new) :
Active use score 17:18h
